GM Load Cell GML-Z4 A Series
The robust and well-designed load cell from General Measure, with the C2/C3 grade accuracy. GML-Z4 A Series canister load cell has the material option of alloy steel and stainless steel. It is compact and easy to install. The weighing capacity is from 10t to 50t, which is usually used for floor scale, truck scale, railway scale, silo scales, and tank scale. It can fulfill a wide range of industries that require accurate measurements, avoiding product waste and saving costs.
ENQUIRE
PRODUCT ENQUIRE
Weighing Capacity
- 10t
- 15t
- 20t
- 30t
- 40t
- 50t
IP68
Operating Functions
- Self-restoring due to pendulum bearing
- Optimized for parallel connection by corner pre-adjustment
Multiple Applications
- Hopper scale
- Belt scale
- Batching scale
 |
 |
 |
 |
