GM Load Cell GML-Z4 D Series
The robust and well-designed load cell from General Measure, with the C3 grade accuracy. GML-Z4 A Series canister load cell has alloy steel and stainless steel as the material options. It is compact and easy to install. The weighing capacity is from 5t to 100t, which is usually used for floor scale, truck scale, railway scale, silo scales, and tank scale. It can fulfill a wide range of industries that require accurate measurements, avoiding product waste and saving costs.
ENQUIRE
PRODUCT ENQUIRE
Weighing Capacity
- 5t, 7.5t, 10t
- 22.5t, 25t
- 30t, 40t, 50t
- 100t
IP68
Operating Functions
- Self-restoring due to pendulum bearing
- Optimized for parallel connection by corner pre-adjustment
Multiple Applications
- Hopper scale
- Belt scale
- Batching scale
 |
 |
